e.bloxx Module A1 ■ 1, 4 or 8 universal input channelsVoltage, current, resistance, Pt100, Pt1000, thermocouples, meaurement bridges■ 1 digital input per channelStatus, reset■ 1 solid state relay output per channelStatus, alarm, threshold, tolerance band■ ADC-conversion and signal conditioning with 19 bit up to 1000/sLinearization, digital filter, average, scaling, min/max memory, arithmetics■ RS 485 fieldbus interfaceProfibus-DP, Modbus-RTU, ASCII e.bloxx Module A2 ■ 1 general purpose analog input channelstrain gauge, piezo resistive bridges, and ICP sensors, voltage, current■ 1 digital input and 1 digital outputStatus, zero balance, memory reset, alarm, limit value, tolerance band■ Signal conditioningLinearization, digital filtering, averaging, scaling, minimum/maximum store, true RMS value, arithmetic■ TEDS functionalityReading of Transducer Electronic Data Sheet from a TEDS sensor module and setup of the A2 internals automatically (IEEE 1451.4 Class 2)■ RS 485 fieldbus interfaceModbus-RTU, ASCII, and Local Bus to Test Controller e.bloxx Module A3 ■ 4 or 16 galvanic isolated voltage / current input channelsDifferential voltage, current (with e.bloxx Terminal 4C), galvanically isolated 100VDC■ Sample rate 100/s with 4 active channelsModule sample rate 400/s■ 1 digital input and 1 digital outputStatus, reset, alarm, threshold, tolerance band■ ADC-conversion and signal conditioning with 19 bitLinearization, digital filter, average, scaling, min/max memory, arithmetics■ RS485 fieldbus interfaceProfibus-DP, Modbus-RTU, ASCII e.bloxx Module A4TC ■ 4 or 16 galvanic isolated Thermocouple input channelsThermocouples, voltages ±80 mV■ Dynamic linearizationOptimized use of base points for type B, E, J, K, L, N, R, S, T, U, import of individual curves■ ADC-conversion and signal conditioning with 19 bit and up to 100/sLinearization, digital filter, average, scaling, min/max memory, arithmetics■ RS485 fieldbus interfaceProfibus-DP, Modbus-RTU, ASCII e.bloxx Module A5 ■ RTD input modulePt100/Pt1000, resistance in 2, 3 or 4 wire■ 1 digital inputStatus, reset■ 1 digital outputAlarm, threshold, tolerance band■ ADC-conversion and signal conditioning with 19 bitLinearization, digital filter, average, scaling, min/max memory, arithmetics■ RS485 fieldbus interfaceProfibus-DP, Modbus-RTU, ASCII e.bloxx Module A5CR ■ 2 Input channels for Cryo sensorse.g. Type Cernox or TVO■ Sensor excitation 8 μAeff onlyto avoid self heading of the sensor■ Individual linearization of the sensor characteristicsSensor specific linearization by using 64 nodes and archive in a sensor data file (import function).■ 1 digital input, 1 digital outputStatus, alarm, limit value, tolerance band■ RS 485 fieldbus interfaceProfibus-DP, Modbus-RTU, ASCII e.bloxx Module A6-2CF ■ Universal carrier frequency sensor connectionStrain gauges full, half and quarter bridges, inductive bridges, LVDT■ 6 digital inputs and 4 digital outputsFunctions definable, e.g. memory delete, frequency measurement, counter, alarm, threshold, tolerance band, status■ 2 analog outputs±10 V, any variable attributable, e.g. netto and envelope curve■ ADC-conversion and signal conditioning with 19 bit and 5000/sLinearization, digital filter 4th pole, scaling, tare, min/max memory, run/hold, envelope curve, arithmetics, alarm, threshold, tolerance band■ RS485 fieldbus interfaceProfibus-DP, Modbus-RTU, ASCII e.bloxx Module A9 ■ 4 analog outputsVoltage ±10 V and current 4..20 mA selectable■ 16 bit DACConversion rate up to 1000/s■ 1 digital input and 1 digital outputStatus, tara, reset, alarm, threshold, tolerance band■ Signal conditioningScaling, min/max memory, arithmetics■ RS485 fieldbus interfaceProfibus-DP, Modbus-RTU, ASCII e.bloxx Module D1 ■ 8 to 32 digital in/outputsfreely configurable■ Status in-/outputProcess or host controlled■ Frequence in-/outputChronos method for precise and fast frequence measurement up to 2 MHz, frequency and PWM output■ Counter inputQuadrature counter, Up/Down counter up to 400 kHz■ RS485 fieldbus interfaceProfibus-DP, Modbus-RTU, ASCII e.bloxx Module D2 ■ 4 relay outputs2 closing contacts and 2 switchable contacts■ Switching of electrical power230 VAC / 3 A, 30 VDC / 3 A■ Many operationsExpected mechanical life-span: 50,000,000 cycles■ RS485 fieldbus interfaceProfibus-DP, Modbus-RTU, ASCII e.bloxx Module D3 ■ e.bloxx D3-CAN - CAN input and outputCAN node 2.0A / 2.0B ref. to ISO 11898■ e.bloxx D3-COM - RS-485 und RS-232 MasterFor connecting of serial devices and fieldbus slaves, standard protocol Modbus-RTU, others on request■ e.bloxx D3-SSI - RS-422 MasterFor connection absolute encoders (e.g. angle, displacement) with SSI (serial synchrony interface)■ 6 digital inputs and 4 digital outputsDefinition of functions like status, alarm or counter■ RS-485 fieldbus (slave) interfaceProfibus-DP, Modbus-RTU, ASCII e.gate Above a certain number of measurement or I/O modules it might be useful to increase the capability and the data rate with one or several e.gates. e.g. up to 120.000 values per second will be posssible via Profibus-DP. ■ Profibus DP / EtherCAT / CANopen and Ethernet interfacesHigh throughput data access for synchronous or asynchronous collection■ High speed data sampling and transmission rateUp to 48.000 real values/s, input and output data■ Recording of a high number of channelsProfibus-DP: 244 byte, max. 120 integer or 60 real valuesEthernet: 1024 byte, max. 304 integer or 192 real valuesEtherCAT: 1024 ByteCANopen: Dynamically, regarding numbers of PDOs■ Internal data buffer memory (16 MB)Data buffer at block transfer of measurements (FTP/Socket)■ Open file structureTotal integration in OEM automation systems, access to all configuration parameters and variables via text files and FTP e.pac With the e.pac any functionality can be defined with several quantities, I/O's, calculations, timing elements, controllers, and these can be stored to the e.pac measurement system. After loading the function into the e.pac it will run autarkic without PC. ■ Extensive function block librarySequences, data archive, PID-controller and further transfer functions, mathematic, numeric, Boolean combinations, function generator■ Data memory 16 Mbytes (DL-version 128 Mbytes Flash)Configurable memory for measurements, I/Os and conditioned variables■ SynchronizingSynchronized data acquisition and PAC functionality up to 1 kHz■ Open file structureTotal integration in OEM automation systems, access to all configuration parameters and variables via text files and FTP■ Ethernet, Profibus (DP-version), EtherCAT (EC-version) and USB (DL-Version) interfacesTime synchronous access to synchronized and asynchronized data e.reader ■ 8 analog inputsVoltage, current, resistance measurement, Pt100/Pt1000, and power supply for external sensors■ Analog/digital conversionResolution of 19 bit, sample rate 1 s up to 24 h■ 6 digital in/outputs and 2 relays outputsStatus, counter, frequency measurement■ Data memory with individual logging interval128 MB flash, 16 MB RAM, 1 s up to 24 h individual per channel■ Low power consumption in power sleep mode50 mW/200 mW at a sample rate of 10 min /10 s■ Flexible communicationsRS485, RS232, Ethernet TCP/IPModem: FTP via PPP, GPRS via VPN TunnelFTP client and FTP serveremail generator with data attachment■ PAC functionalitySequences, calculations, combinations, evaluations, decisions
