Q.bloxx Module A101 ■ 2-채널,유니버셜 입력모듈전압,전류,저항,전위차,온도(RTD/TC),스트레인, IEPE-가속도센서■ 고분해능,고속샘플링24 bit ADU, 채널당 100 kHz 샘플링■ 채널당 1-디지털 입력 또는 출력 입력: state, tare, memory reset출력: state alarm, thresh hold■ 시그널 컨디셔닝16 virtual channels, linearization, digital filter, average, scaling, min/max storage, RMS, arithmetic, alarm■ TEDSclass 1 과 class 2, according IEEE 1541.4■ RS485 필드버스 인터페이스up to 48 Mbps: LocalBusup to 115.2 kbps: Modbus-RTU, ASCII■ 지원되는 어떤 콘드롤러도 연결 가능e.g. Q.gate or Q.pac■ 완벽한 절연입출력 신호, 전원공급 그리고 인터페이스 통신에 대해500 VDC 까지의 완벽한 절연■ Electromagnetic Compatibilityaccording EN 61000-4 and EN 55011■ 전원공급: 10…30 VDC■ DIN rail mounting (EN 50022) Q.bloxx Module A102 ■ 1 analog input channelmeasuring bridge (full, half, quarter), IEPE-sensors, voltage, current■ 1 analog outputvoltage ±10 V and current 0 up to 25 mA selectable, 100 kHz■ Fast high accuracy digitalization19 Bit ADC - SAR (without delay time), 100 kHz sample rate■ 4 digital inputs, 2 digital outputseinput: state, tare, memory resetoutput: state alarm, thresh hold■ Signal conditioning16 virtual channels, linearization, digital filter, average, scaling, min/max storage, RMS, arithmetic, alarm■ TEDSclass 1 and class 2, according IEEE 1541.4■ RS485 fieldbus-interfaceup to 48 Mbps: LocalBusup to 115.2 kbps: Modbus-RTU, ASCII■ Additional RS 485 fieldbus interfaceto control an 8-channel multiplexer for multi channel systems, 10 Hz per channel■ Galvanic isolationof I/O-signals, power supply and interfaceIsolation voltage 500 VDC■ Electromagnetic Compatibilityaccording EN 61000-4 and EN 55011■ Power supply 10…30 VDC■ DIN rail mounting (EN 50022) Q.bloxx Module A103 ■ 8 galvanic isolated input channelsdifferential voltage, current via shunt connectorIsolation voltage 100 VDC■ High accuracy digitalization24 bit ADU, 100 Hz sample rate per channel with 8 active channels, sum sample rate 800 Hz■ 2 digital in and 2 outputsinput: state, tare, memory resetoutput: state alarm, thresh hold■ Signal conditioninglinearization, digital filter, average, scaling, min/max storage, arithmetic, alarm■ RS485 fieldbus-interfaceup to 48 Mbps: LocalBusup to 115.2 kbps: Modbus-RTU, ASCII■ Connectable to any Test Controllere.g. Q.gate or Q.pac■ Galvanic isolationof I/O-signals, power supply and interfaceIsolation voltage 500 VDC■ Electromagnetic Compatibilityaccording EN 61000-4 and EN 55011■ Accuracy class 0.01■ Power supply 10…30 VDC■ DIN rail mounting (EN 50022) Q.bloxx Module A104 ■ 8 galvanic isolated input channelsthermocouples and voltages in the range of ±80 mV Isolation voltage 100 VDC■ Cold junction compensationgood thermal coupling by means of cold junction compensation per connector■ Dynamic linearizationoptimized positioning of the interpolation points within the selected range, type B, E, J, K, L N, R, S, T, U■ High accuracy digitalization24 bit ADU, 100 Hz sample rate per channel with 8 active channels, sum sample rate 800 Hz■ Signal conditioningdigital filter, average, scaling, min/max storage, arithmetic, alarm■ RS485 fieldbus-interfaceup to 48 Mbps: LocalBusup to 115.2 kbps: Modbus-RTU, ASCII■ Connectable to any Test Controllere.g. Q.gate or Q.pac■ Galvanic isolationof I/O-signals, power supply and interfaceIsolation voltage 500 VDC■ Electromagnetic Compatibilityaccording EN 61000-4 and EN 55011■ Accuracy class 0,01■ Power supply 10…30 VDC■ DIN rail mounting (EN 50022) Q.bloxx Module A107 ■ 4 universal analog input channelsvoltage, current, resistance, potentiometer, Pt100, Pt1000, thermocouples, measuring bridges■ Fast high accuracy digitalization24 bit ADU, 10 kHz sample rate per channel■ Signal conditioning16 virtual channels, linearization, digital filter, average, scaling, min/max storage, RMS, arithmetic, alarm■ RS485 fieldbus interfaceup to 48 Mbps: LocalBusup to 115.2 kbps: Modbus-RTU, ASCII■ Connectable to any Test Controllere.g. Q.gate or Q.pac■ Galvanic isolationof I/O-signals, power supply and interface■ Electromagnetic Compatibilityaccording EN 61000-4 and EN 55011■ Power supply 10…30 VDC■ DIN rail mounting (EN 50022) Q.bloxx Module A108 ■ 8 galvanic isolated input channelsdifferential voltage, current via shunt connector Isolation voltage 100 VDC■ High accuracy digitalization24 bit ADU, 10 kHz sample rate per channel with 8 active channels, sum sample rate 80 kHz■ 2 digital in and 2 outputsinput: state, tare, memory resetoutput: state alarm, thresh hold■ Signal conditioninglinearization, digital filter, average, scaling, min/max storage, RMS, arithmetic, alarm■ RS485 fieldbus-interfaceup to 48 Mbps: LocalBusup to 115,2 kbps: Modbus-RTU, ASCII■ Connectable to any Test Controllere.g. Q.gate or Q.pac■ Galvanic isolationof I/O-signals, power supply and interfaceIsolation voltage 500 VDC■ Electromagnetic Compatibilityaccording EN 61000-4 and EN 55011■ Accuracy class 0,01■ Power supply 10…30 VDC■ DIN rail mounting (EN 50022 rail) Q.bloxx Module A109 ■ 4 galvanic isolated analog output channelsvoltage ±10 V, current 4…20 mA selectable Isolation voltage 500 VDC■ DAC-resolution 16 bit100 kHz with 1 channel, 10 kHz with 4 channels■ 4 digital inputs and 4 digital outputsconfigurable as 2 counter, 2 frequency, or 2 PWM inputs, 2 frequency or PWM output, state in or output■ Frequency in and outputsfrequency measurement up to 1 MHz (Chronos method),frequency output up to 10 kHz■ CounterFor/backward counter, quadrature counter with reference zero recognition (reset/enable), up to 1 MHz■ PWM in and outputmeasurement of duty cycle and frequency, output with variable frequency and/or duty cycle■ Outputs freely scalable■ RS485 fieldbus-interfaceup to 48 Mbps: LocalBus, up to 115.2 kbps: Modbus-RTU, ASCII■ Galvanic isolationof I/O-signals, power supply and interfaceIsolation voltage 500 VDC■ Electromagnetic Compatibilityaccording EN 61000-4 and EN 55011■ Power supply 10…30 VDC■ DIN rail mounting (EN 50022) Q.bloxx Module D101 ■ 8 digital inputs and 8 digital outputsconfigurable as counter, frequency, PWM and time inputs, frequency or PWM output, state in or output■ State in and outputsprocess- and host controlled■ Frequency in and outputsfrequency measurement up to 1 MHz (Chronos method), frequency output up to 10 kHz■ Counterfor/backward counter, quadrature counter with reference zero recognition (reset/enable), up to 1 MHz■ PWM in and outputsmeasurement of duty cycle and frequency, output with variable frequency and/or duty cycle■ Time measurement■ RS485 fieldbus-interfaceup to 48 Mbps: LocalBusup to 115.2 kbps: Modbus-RTU, ASCII■ Connectable to any Test Controllee.g. Q.gate or Q.pac■ Galvanic isolationof I/O-signals, power supply and interfaceIsolation voltage 500 VDC■ Electromagnetic Compatibilityaccording EN 61000-4 and EN 55011■ Power supply 10…30 VDC■ DIN rail mounting (EN 50022) Q.gate IP / DP ■ Connection of up to 32 Q.bloxx modulesvia 2 UARTS, Baud rate up to 24 MBaud each UART■ Recording of up to 256 variablesreal format 4 Byte■ Synchronization and time stamp of measurement values■ Ethernet interface for configuration and data outputFTP, TCP/IP, UDP■ FTP Server and FTP Client functionalityconfigurable function■ Optional fieldbus interfaceProfibus-DP, 12 Mbps■ High data rate over Ethernet128 real variables with 1 kHz (block transfer)16 real variables with 10 kHz (block transfer)64 real variables with 300 Hz (online)■ Data buffer memory 12 MByteData buffer at block transfer of measurements■ Mathematic, control and combination features■ PAC functionality with extensive function block librarySequences, data logger, PID-controller, transfer functions, mathematic, numeric, Boolean combinations, functions generator■ Galvanic isolationof power supply and interfaces■ Electromagnetic Compatibilityaccording EN 61000-4 and EN 55011■ Power supply 10…30 VDC■ DIN rail mounting (EN 50022) Q.pac DL / EC ■ Connection of up to 32 Q.bloxx modulesvia 4 UARTS, Baud rate up to 24 MBaud each UART■ Recording of up to 256 variablesreal Format 4 Byte■ Synchronization and time stamp of measurement values■ Ethernet interface for configuration and data outputFTP, TCP/IP, UDP■ FTP Server and FTP Client functionalityconfigurable function■ Optional fieldbus interfaceEtherCAT according specification ETG■ High data rate over Ethernet128 real variables with 1 kHz (block transfer)16 real variables with 10 kHz (block transfer)64 real variables with 300 Hz (online)■ Data buffer memory dyn. 12 MByte, stat. 128 MByteData buffer at block transfer of measurements■ PAC functionality with extensive function block librarySequences, data logger, PID-controller, transfer functions, mathematic, numeric, Boolean combinations, functions generator■ Galvanic isolationof power supply and interfaces■ Electromagnetic Compatibilityaccording EN 61000-4 and EN 55011■ Power supply 10…30 VDC■ DIN rail mounting (EN 50022)
