* 0.015% 정확도, 1mA 분해능 * 0~20mA, 4~20mA 루프전류 측정 * PLCs, Transmitters의 출력신호의 전압측정 * 24mA 루프전류를 소스 및 시물레이트 * 100mV나 10V까지의 전압소스 공급 * 24V 루프전원 공급과 동시에 전류 측정 * HART통신용 250 ohm 저항 탑재 * Step 및 Ramp 기능 * 설정 가능한 Zero 및 Span 기능   Functional specifications Measure / Source mV Range: 0 to 200 mV Resolution: 0.01 mV Accuracy: 0.015% + 2 counts Measure / Source V Range: 0 to 20 V Resolution: 0.001 V Accuracy: 0.01% + 2 counts Measure / Source/ Simulate mA (% of span) Range: 0 to 24 mA (-25% to 125%) Resolution: 0.001 mA Accuracy: 0.01% + 2 counts Note: Sink (simulate transmitter) Display mA or % of span Specifications Loop Power Range: 24 V dc Accuracy: +/- 10% Note: Drive; 20 mA into 1000 Ω for battery >6.8V; 700 Ω for battery 5.8 to 6.8 V Display Clear 5 digit LCD Environmental Specifications Operating Temperature -10ºC to 55ºC Storage Temperature -40ºC to 60ºC Humidity (Without Condensation) 95% (10 ºC to 30 ºC) 75% (30 ºC to 40 ºC) 45% (40 ºC to 50 ºC) 35% (50 ºC to 55 ºC) Operating Altitude 3,000m max Safety Specifications Safety CSA C22.2 No. 1010.1:1992 Mechanical & General Specifications Size 187 mm L x 87mm W x 32 mm (7.93 in. L x 3.86 in. W x 2.06 in D) Weight Approx. 330 g (21 oz) Warranty 3 years Shock & Vibration Random, 2G, 5-500 Hz 1m drop test Battery type Single 9V battery ANSI/NEDA 1604A or IEC 6LR619V alkaline
